Gold Wash Plante Rotary Trommel Vibrating Screen Capacity 10T/H For Mineral Screening

Name: Gold Wash Plante Rotary Trommel Vibrating Screen Capacity 10TH For Mineral Screening
Brand: headdredging
Price: 5000 USD

Gold Wash Plante Rotary Trommel Vibrating Screen Capacity 10T/H For Mineral Screening Manufactures

Brand Name : headdredging

Model Number : J10

Place of Origin : CHINA

MOQ : 1

Price : USD5000-10000/SET

Payment Terms : L/C, L/C, T/T

Name : Gold Wash Plant

Processing capacity : 5-10t/h

Screen size (mm) : 530(Dia.)*1800(Length)

Mesh : 8mm

Water pump : 2inch with water pipe

Application : gold wash, gold screen,gold mining

Contact Now

Small Gold Wash Plant Rotary Trommel Vibrating Screen Working Capacity 10T/H For Mineral Screening

Description Of The Gold Washing Plant Rotary Trommel Vibrating Screen

A trommel is a screen that is curved into a cylinder. The machine spins the cylindrical screen in order to sort through the material as it is fed through.The cylindrical drum has many holes of a given size. The holes help in classification, and when the drum rotates it only lets the material smaller than the holes fall through while the rest of the material flows out of the other end of the trommel.

A gold trommel is a piece of mining equipment that is quite popular and is used all around the world on all different sized mining operations.When gold bearing material is added to the hopper, it is washed down by jets of water to break up the material and help release the gold.

Gold Wash Plante Rotary Trommel Vibrating Screen Capacity 10T/H For Mineral Screening

Avantage of The Gold Washing Plant

1. This screening method helps reduce operating and investment costs

2. Improve product quality and strong processing capacity.

3.low investment, less labor, return on investment fast, easy to operate, easy to move and so on.

Gold Wash Plante Rotary Trommel Vibrating Screen Capacity 10T/H For Mineral Screening

Specifications of he Gold Washing Plant

Model	KDTJ-10 Gold Trommel	KDTJ-5 Gold Trommel
Machine size(mm)	2900 12001500	28001350 1150
Processing capacity	5-10t/h	1-5t/h
Screen
Screen size (mm)	530(Dia.)*1800(Length)	400(Dia.)*1300(Length)
Mesh	8mm	8mm
Driven type	by belt	by belt
Diesel engine	Portable Diesel Engine	Portable Diesel Engine

	with CE Certificate	with CE Certificate
Oil Tank	2.5L	2.5L
Feeder hopper(mm)	1200*810	1066*568
Gold Felt
rough gold felt(mm)	2000*600(1pc)	1500*400(1pc)
fine gold felt(mm)	2000*600(1pc)	1500*400(1pc)
Water pump	2inch with water pipe	2inch with water pipe
